Communication Protocols — HTTP, WebSockets, gRPC & SSE

The Story: Ways to Communicate in a City

HTTP (Request-Response): You send a letter, wait for a reply. You initiate, server responds. Done.
WebSockets: You open a phone call. Both can speak at any time. The line stays open.
gRPC: A highly efficient internal memo system between departments — structured, typed, fast.
Server-Sent Events: A news broadcast. Server pushes updates. You only listen.
Long Polling: You call the office and wait on hold until they have an answer.

HTTP / HTTPS

HTTP (HyperText Transfer Protocol) is the protocol of the web. Every API call, every web page request, every REST call is HTTP.

Request-Response cycle:

Client → [HTTP Request]  → Server
Client ← [HTTP Response] ← Server
Connection closes (HTTP/1.1: may keep-alive, HTTP/2: multiplexed)

HTTP Versions

Version	Key improvement	Connection
HTTP/1.0	Original	New TCP connection per request
HTTP/1.1	Keep-alive, pipelining	Reuse connection, but HOL blocking
HTTP/2	Multiplexing, header compression, server push	Multiple requests in parallel on one connection
HTTP/3	Built on QUIC (UDP)	Eliminates TCP HOL blocking, faster reconnection

Head-of-Line (HOL) blocking in HTTP/1.1: Requests are served in order on a connection. If request 1 is slow, requests 2–10 wait even if they’re ready. HTTP/2 multiplexing sends all in parallel on one connection.

HTTP Methods

Method	Operation	Idempotent?	Body?
GET	Read	Yes	No
POST	Create	No	Yes
PUT	Replace entire resource	Yes	Yes
PATCH	Partial update	No	Yes
DELETE	Delete	Yes	No
HEAD	Like GET, but no body	Yes	No

Idempotent: Calling the same request multiple times has the same effect as calling it once. Important for retry logic.

HTTP Status Codes

2xx — Success
  200 OK                     →  success
  201 Created                →  resource created (POST)
  204 No Content             →  success, no body (DELETE)

3xx — Redirection
  301 Moved Permanently      →  browser caches, SEO-safe
  302 Found                  →  temporary redirect
  304 Not Modified           →  browser uses cached version

4xx — Client Error
  400 Bad Request            →  malformed request
  401 Unauthorized           →  not authenticated
  403 Forbidden              →  authenticated but not allowed
  404 Not Found              →  resource doesn't exist
  409 Conflict               →  state conflict (e.g., duplicate username)
  422 Unprocessable          →  validation failure
  429 Too Many Requests      →  rate limited

5xx — Server Error
  500 Internal Server Error  →  generic server crash
  502 Bad Gateway            →  upstream service unreachable
  503 Service Unavailable    →  server overloaded or down
  504 Gateway Timeout        →  upstream too slow

REST Design Principles

REST (Representational State Transfer) is an architectural style for HTTP APIs.

Key principles:

Resources are nouns (not verbs):

✅ GET    /users/42           → get user 42
✅ POST   /users              → create user
✅ PUT    /users/42           → update user 42
✅ DELETE /users/42           → delete user 42

❌ GET    /getUser?id=42
❌ POST   /createUser
❌ POST   /deleteUser/42

Stateless: Every request contains all information needed. No server-side session state.
Hierarchical URLs reflect relationships:

/users/42/orders           → orders belongs to user 42
/users/42/orders/101       → specific order 101 belongs to user 42
/users/42/orders/101/items → items in the order 101 belongs to user 42

Use query params for filtering, sorting, pagination:

GET /products?category=electronics&sort=price_asc&page=2&limit=20

Version your API:

GET /api/v1/users/42     ← current
GET /api/v2/users/42     ← new version with breaking changes

WebSockets: The Open Phone Line

What WebSockets solve

HTTP is request-response. The client always initiates. What if the server needs to push data to the client?

Problem scenarios:

Chat: other users’ messages appear without you refreshing
Live scores: score updates automatically
Stock prices: real-time price changes
Collaborative editing: see others’ cursor movements

Naive solution: polling

Client: every 1 second → "Any new messages?"
Server: "No"
Client: "Any new messages?"
Server: "No"
Client: "Any new messages?"
Server: "Yes! Here it is."

99% of requests return "No" — wasted bandwidth and latency

WebSocket solution: Persistent, full-duplex connection. Both sides can send at any time.

WebSocket Handshake

WebSockets upgrade from HTTP:

Client → Server: HTTP upgrade request
GET /chat HTTP/1.1
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==

Server → Client: 101 Switching Protocols
HTTP/1.1 101 Switching Protocols
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Accept: s3pPLMBiTxaQ9kYGzzhZRbK+xOo=

--- Connection is now a WebSocket ---

Server → Client: "{'type':'message','text':'Hello!'}"  (any time)
Client → Server: "{'type':'message','text':'Hi back!'}"  (any time)

WebSocket use cases

Use case	Why WebSocket?
Chat applications	Bidirectional real-time messaging
Live sports scores	Server pushes score updates
Collaborative documents	Real-time cursor and edit sync
Online gaming	Low latency bidirectional state updates
Live trading dashboards	Sub-second price updates
IoT device monitoring	Continuous sensor data streams

WebSocket scaling challenges

Problem: User opens WebSocket → connects to Server 1
         User A and User B must be on same server to chat directly

Solution options:
1. Sticky sessions: Load Balancer routes same user to same server always
   - Problem: server failures lose all connections

2. Pub/Sub broker (Redis Pub/Sub):
   Server 1 (User A) → publishes  → [Redis Pub/Sub channel]
   Server 2 (User B) ← subscribes ← [Redis Pub/Sub channel]
   Server 2 delivers to User B

3. Message broker (Kafka/RabbitMQ):
   Same as above but durable (messages survive crashes)

In production: Use Redis Pub/Sub or a dedicated WebSocket service (Pusher, Ably, AWS API Gateway WebSocket).

Server-Sent Events (SSE)

One-way push from server to client over HTTP. Simpler than WebSockets when you only need server → client.

// Server (Node.js)
app.get("/events", (req, res) => {
	res.setHeader("Content-Type", "text/event-stream");
	res.setHeader("Cache-Control", "no-cache");

	const interval = setInterval(() => {
		res.write(`data: ${JSON.stringify({ price: getStockPrice() })}\n\n`);
	}, 1000);

	req.on("close", () => clearInterval(interval));
});

// Client (JavaScript)
const es = new EventSource("/events");
es.onmessage = (e) => {
	console.log(JSON.parse(e.data));
};

SSE vs WebSockets:

	SSE	WebSockets
Direction	Server → Client only	Bidirectional
Protocol	HTTP	WebSocket (upgraded HTTP)
Reconnection	Automatic	Must implement
Browser support	All modern browsers	All modern browsers
Load balancer	Works with standard HTTP LB	Needs sticky sessions or pub/sub
Use when	News feed, notifications, live updates	Chat, gaming, collaborative

Long Polling

Before WebSockets: The trick to simulate server push with regular HTTP.

Client → "Any new messages?"
Server holds the request open... (up to 30s)
  → New message arrives → Server responds immediately
  → Timeout reached     → Server responds with empty

Client immediately makes another request:
Client → "Any new messages?"
Server holds... → responds when message arrives or timeout

Better than regular polling (requests only return when there’s data), but worse than WebSockets (still request-response, HTTP overhead per message).

Still used by: Some chat systems, webhooks with retry logic, systems where WebSocket infrastructure is unavailable.

gRPC: The High-Performance Internal Messenger

gRPC (Google Remote Procedure Call) is a high-performance RPC framework using Protocol Buffers for serialization and HTTP/2 for transport.

Think of it as calling a function on a remote server as if it were a local function call.

How gRPC works

Define your service in a .proto file:

// service.proto
syntax = "proto3";

service UserService {
  rpc GetUser (GetUserRequest) returns (User);
  rpc ListUsers (ListUsersRequest) returns (stream User);    // streaming!
  rpc CreateUser (stream CreateUserRequest) returns (User);  // client streaming
}

message GetUserRequest {
  int64 user_id = 1;
}

message User {
  int64 id = 1;
  string name = 2;
  string email = 3;
  google.protobuf.Timestamp created_at = 4;
}

Generate client/server code in any language (Python, Go, Java, Rust…):

protoc --python_out=. --grpc_python_out=. service.proto

Implement the server, call from client:

# Client code — looks like a local function call
user = stub.GetUser(GetUserRequest(user_id=42))
print(user.name)  # Ritik

gRPC vs REST comparison

	REST/JSON	gRPC/Protobuf
Protocol	HTTP/1.1 or 2	HTTP/2
Format	JSON (text)	Protobuf (binary)
Size	Larger (verbose)	3–10× smaller
Speed	Slower	~10× faster
Schema	Optional (OpenAPI)	Required (.proto)
Streaming	Not native	Built-in
Browser support	Native	Needs proxy (grpc-web)
Tooling	Mature, widespread	Strong in backend
Best for	External/public APIs	Internal microservices

gRPC streaming modes

Unary:          Client sends one request, gets one response
Server stream:  Client sends one request, server streams many responses
Client stream:  Client streams many requests, server sends one response
Bidirectional:  Both sides stream simultaneously

Bidirectional streaming example: Real-time audio transcription

Client streams: audio chunks
Server streams: transcript updates
Both happening simultaneously

Choosing the Right Protocol

Public API (browser/mobile clients)?
    → REST/HTTP — universal support, familiar, easy to debug

Internal microservice-to-microservice?
    → gRPC — faster, type-safe, streaming support

Real-time server → client updates (news, notifications, prices)?
    → Server-Sent Events — simple, works with HTTP

Real-time bidirectional (chat, gaming, collaborative)?
    → WebSockets — persistent connection, low latency

Need support across languages + existing HTTP infrastructure?
    → REST wins (pragmatic choice)

Need maximum performance + you control all clients?
    → gRPC wins

Webhooks: The Reverse API

Traditional API: you call the server to check for updates.
Webhook: the server calls you when something happens.

Traditional polling:
You → "Did the payment succeed?" (every 5 seconds)
Server: "No"... "No"... "No"... "Yes!"

Webhook:
You register: "POST https://your-server.com/webhook when payment completes"
Server: (when payment completes) → POST https://your-server.com/webhook { status: "success" }

Design considerations:

Webhooks can fail (your server might be down)
Implement retry with exponential backoff on the webhook sender side
Make your webhook endpoint idempotent (deduplication ID)
Always verify the webhook signature (HMAC-SHA256) to prevent spoofing

import hmac, hashlib

def verify_webhook(payload, signature, secret):
    expected = hmac.new(secret.encode(), payload, hashlib.sha256).hexdigest()
    return hmac.compare_digest(expected, signature)

Flashcards

Q: REST vs WebSocket vs gRPC — when to use each?

REST is my default for external APIs — universally supported, easy to debug, works everywhere. WebSockets for real-time bidirectional communication like chat or collaborative editing where the server needs to push data unprompted. gRPC for internal microservice communication where I need high throughput, type safety, and streaming — it’s 10× faster than REST due to binary Protobuf serialization over HTTP/2.

Q: How would you implement real-time notifications?

Server-Sent Events for one-way pushes (notifications, live feeds) — they’re simple, work over HTTP, and reconnect automatically. WebSockets if users need to interact in real time (chat, collaborative features). For scale, I’d put Redis Pub/Sub behind the WebSocket servers so messages route correctly regardless of which server a client is connected to.

Q: What is the difference between HTTP/1.1 and HTTP/2?

HTTP/2 adds multiplexing (multiple requests in parallel on one connection), header compression, and server push, eliminating the head-of-line blocking of HTTP/1.1.

Q: When should you use WebSockets vs SSE?

WebSockets for bidirectional communication (chat, gaming). SSE for server-to-client only (notifications, live feeds, prices). SSE is simpler and auto-reconnects.

Q: What makes gRPC faster than REST?

Binary Protobuf serialization (smaller payloads), HTTP/2 multiplexing (parallel requests), and generated typed code (no JSON parsing).

Q: What is a webhook and what’s the main reliability concern?

A webhook is a server calling your endpoint when an event occurs. Main concern: your endpoint might be down. Sender must implement retries with backoff. Your endpoint must be idempotent.

Q: What HTTP status code means the resource was created successfully?

201 Created.

Q: What is head-of-line blocking in HTTP/1.1?

Requests are served in order on a connection. A slow request blocks all subsequent requests. HTTP/2 multiplexing eliminates this.
