CDNs, Load Balancers & Proxies

The Story: Highways, Traffic Cops, and Local Shops

Load Balancer: The traffic cop at the city gate. Every car entering the city is directed to the least-congested road.
Reverse Proxy: The city’s reception desk. You never talk directly to departments — you talk to the receptionist who routes you.
Forward Proxy: The city’s VPN exit. You send your messages through a representative who talks to the outside world on your behalf.
CDN: Local shops in every neighbourhood stocked with the most popular goods from the central warehouse.

CDN: Content Delivery Networks

How a CDN works

A CDN is a globally distributed network of servers (called Points of Presence / PoPs / edge servers) that cache content close to end users.

Without CDN:
User in Delhi → request → Origin Server in Virginia → 300ms round trip

With CDN:
User in Delhi → request → CDN PoP in Delhi → <10ms (cached content)
                                           → cache miss → Virginia → cache → serve

CDN flow:

1. User requests https://ritiktiwari.com/resume.pdf
2. DNS resolves to nearest CDN edge (Anycast routing)
3. Edge checks cache:
   HIT  → serve instantly (milliseconds)
   MISS → fetch from origin (ritiktiwari.com) → cache → serve
4. Next user in same region gets HIT

Push CDN vs Pull CDN

Pull CDN: Content pulled from origin on first request, cached at edge.

User requests → CDN misses → CDN fetches from origin → caches → serves

Low setup overhead (no pre-uploading)
First user in each region gets slow response (cold cache)
Good for: large, unpredictable content catalogs

Push CDN: You explicitly push content to edge nodes before users request it.

Deploy new image → Push to all CDN edges globally → Users always hit cache

Always fast (no cold miss)
More complex (must manage pushes)
Good for: known-popular content, marketing launches, games

Cache-Control headers — the language of CDNs

Cache-Control: public, max-age=31536000, immutable

Directive	Meaning
`public`	CDNs and browsers may cache this
`private`	Browser only, not CDN (personalised content)
`max-age=N`	Cache for N seconds
`no-cache`	Must revalidate before serving from cache
`no-store`	Never cache
`immutable`	Content will never change (bust by URL, not headers)
`s-maxage=N`	CDN-specific TTL (overrides max-age for CDN)

URL-based cache busting

For files with max-age=31536000 immutable, how do you update them?

<!-- Old version: cached forever -->
<script src="/app.js?v=1.0.0"></script>

<!-- New deploy: new URL → cache miss → fresh download -->
<script src="/app.js?v=1.2.3"></script>

<!-- Or: content hash (Webpack, Vite, etc.) -->
<script src="/app.abc123def456.js"></script>

The URL changes → CDN treats it as a brand new resource → serves fresh content.

CDN for dynamic content

CDNs aren’t just for static assets. Modern CDNs can cache:

API responses (with Cache-Control: public, s-maxage=60)
Rendered HTML pages
Database query results (via edge computing)

Edge computing (Cloudflare Workers, AWS Lambda@Edge): Run serverless code at the CDN edge — personalisation, A/B testing, auth without hitting origin.

// Cloudflare Worker — runs at edge globally
addEventListener("fetch", (event) => {
	event.respondWith(handleRequest(event.request));
});

async function handleRequest(request) {
	const country = request.cf.country;
	if ("IN" === country) {
		return fetch("https://india.api.example.com" + request.url);
	}
	return fetch("https://us.api.example.com" + request.url);
}

Major CDN providers

Provider	Strengths
Cloudflare	Security (DDoS), edge compute, free tier, easiest setup
AWS CloudFront	Deep AWS integration, Lambda@Edge
Fastly	Instant purge (<150ms), real-time config, Varnish-based
Akamai	Largest network, enterprise, media streaming

Load Balancers

What does a load balancer do?

A load balancer distributes incoming traffic across multiple servers, preventing any one server from becoming a bottleneck.

                   ┌─→ [App Server 1]
[Clients] → [LB] ──┼─→ [App Server 2]
                   └─→ [App Server 3]

Additional responsibilities (modern LBs):

Health checking (stop sending traffic to failed servers)
SSL/TLS termination (decrypt HTTPS, forward HTTP internally)
Sticky sessions (route same user to same server)
Request logging and metrics
Connection draining (gracefully remove server during deployment)

Load Balancing Algorithms

Round Robin

Requests go to servers in rotation: 1, 2, 3, 1, 2, 3…

Request 1 → Server 1
Request 2 → Server 2
Request 3 → Server 3
Request 4 → Server 1  (cycles)

Best for: Servers with equal capacity. Requests take similar time.

Weighted Round Robin

Same as round robin but servers get traffic proportional to weight.

Server 1: weight=3 → gets 60% of traffic
Server 2: weight=2 → gets 40% of traffic
Order: 1,1,1,2,2,1,1,1,2,2...

Best for: Mixed server capacities (some servers are more powerful).

Least Connections

New request goes to the server with fewest active connections.

Server 1: 47 active connections
Server 2: 12 active connections  ← send next request here
Server 3: 31 active connections

Best for: Long-lived connections (chat, file uploads). Variable request duration.

Least Response Time

Send to the server with the lowest average response time.

Best for: When server response times vary significantly.

IP Hash

server = hash(client_IP) % number_of_servers

Same client always goes to same server.

Best for: Session stickiness when you can’t use distributed session storage.
Downside: Uneven distribution if many users share an IP (corporate NAT). Breaks if you add/remove servers (hash changes).

Consistent Hashing (for L7)

Same concept as DB sharding — used in service meshes (Envoy) for session affinity without the problems of IP hash.

Layer 4 vs Layer 7 Load Balancing

	L4 (Transport)	L7 (Application)
Operates at	TCP/UDP	HTTP, gRPC
Routing based on	IP + Port	URL, headers, cookies, body
Speed	Faster (no content inspection)	Slower (must parse HTTP)
SSL termination	No (or passthrough)	Yes
Content-based routing	No	Yes
Examples	AWS NLB, HAProxy (L4 mode)	AWS ALB, Nginx, HAProxy (L7)

L4 use: TCP/UDP apps, databases, game servers, when minimal overhead matters.
L7 use: HTTP APIs, microservices routing, A/B testing, canary deployments.

Health Checks

LBs continuously check if servers are healthy.

Active health check (LB probes servers):
LB → GET /health → Server 1 → 200 OK  → healthy
LB → GET /health → Server 2 → timeout → unhealthy     → remove from pool
LB → GET /health → Server 2 → 200 OK  → healthy again → return to pool

Passive health check (LB observes traffic):
If >5% of responses to Server 3 are 5xx → mark unhealthy

Connection draining: When removing a server (deployment, maintenance), the LB stops sending new requests but lets existing requests complete.

High Availability for the Load Balancer Itself

The LB is itself a potential SPOF. Solution:

Active-Passive pair:

[Clients] → Virtual IP (VIP)
                  ↓
            [Primary LB] (active, holds VIP)
            [Standby LB] (watches primary via heartbeat)

If Primary fails:
Standby detects → takes over VIP → becomes active
VRRP protocol manages this automatically (<1 second failover)

DNS-based: Multiple LB IPs returned in DNS. Client tries another on failure.

Anycast: Same IP announced from multiple locations — routing naturally directs to closest.

Proxies: Forward and Reverse

Forward Proxy: You → Proxy → Internet

[Client] → [Forward Proxy] → [Internet]

The internet sees the proxy’s IP, not the client’s.

Use cases:

Corporate: route all employee traffic through proxy (filtering, monitoring)
VPN services: hide client IP
Bypass geo-restrictions
Cache responses for all clients on a network

The client configures the forward proxy. The destination server doesn’t know about it.

Reverse Proxy: Client → Proxy → Your Servers

[Client] → [Reverse Proxy] → [Server 1]
                           → [Server 2]

The client sees only the proxy’s IP. Internal servers are hidden.

Use cases:

Load balancing (Nginx, HAProxy)
SSL termination (decrypt HTTPS once, forward HTTP internally)
Caching (Varnish, Nginx)
API gateway (rate limiting, auth)
Security (hide internal architecture)

The client doesn’t know about the reverse proxy. It just talks to the proxy thinking it’s the server.

Nginx as a Reverse Proxy

# nginx.conf — basic reverse proxy
http {
    upstream app_servers {
        least_conn;  # algorithm
        server 10.0.0.1:8080 weight=3;
        server 10.0.0.2:8080 weight=2;
        server 10.0.0.3:8080;  # default weight=1
        keepalive 32;  # connection pool
    }

    server {
        listen 443 ssl;
        server_name api.example.com;

        ssl_certificate /etc/ssl/cert.pem;
        ssl_certificate_key /etc/ssl/key.pem;

        location / {
            proxy_pass http://app_servers;
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_connect_timeout 3s;
            proxy_read_timeout 30s;
        }

        location ~* \.(jpg|png|css|js)$ {
            expires 1y;
            add_header Cache-Control "public, immutable";
            proxy_pass http://app_servers;
        }
    }
}

Service Mesh: Proxies for Microservices

In a microservices world, every service-to-service call needs:

mTLS (mutual authentication)
Retry logic
Circuit breaking
Metrics and tracing
Load balancing

Service mesh: A sidecar proxy runs next to every service instance, handling all of the above transparently.

[Service A] → [Envoy Sidecar A] → [Envoy Sidecar B] → [Service B]
                    ↓                       ↓
                 [Control Plane: Istio / Linkerd]
                (configures all sidecars centrally)

The developer writes service_b.send_request() — the sidecar handles mTLS, retries, circuit breaking automatically.

Tools: Istio (Envoy-based), Linkerd, Consul Connect

Flashcards

Q: Design the traffic ingress for a large system

Traffic enters through Cloudflare for DDoS protection and edge caching of static assets. DNS points to our load balancer cluster (active-passive HA pair using VRRP). The L7 load balancer (AWS ALB or Nginx) does SSL termination, routes to the correct service based on URL path, and health-checks backend servers. Servers receive HTTP internally. For microservice-to-microservice, we use a service mesh (Envoy/Istio) for mTLS, retries, and observability.

Q: When would you use a CDN?

CDN for anything static — JS, CSS, images, videos, downloadable files. Also for API responses that are public and can be cached (product catalog, public content). Cache-Control headers tell the CDN how long to cache. URL-based cache busting for static assets (content hash in filename). Pull CDN for most cases; push CDN for known-popular content before launch.

Q: What is the difference between a forward proxy and a reverse proxy?

Forward proxy acts on behalf of clients (hides client identity). Reverse proxy acts on behalf of servers (hides server infrastructure). Clients configure forward proxies; servers configure reverse proxies.

Q: What does SSL termination mean in load balancing?

The load balancer decrypts HTTPS traffic, then forwards plain HTTP to backend servers. Offloads crypto from app servers.

Q: What is L4 vs L7 load balancing?

L4 routes based on IP and port (fast, no content inspection). L7 routes based on HTTP content (URL, headers, cookies) — enables content-based routing, canary deploys.

Q: What is connection draining?

When removing a server from the pool, the LB stops sending new connections but allows existing connections to complete gracefully.

Q: What is cache busting in CDNs?

Changing the URL of a resource (e.g., including a version hash) so CDNs treat it as a new resource and fetch fresh content from origin.

Q: What is a service mesh?

A network of sidecar proxies that handle inter-service communication concerns (mTLS, retries, circuit breaking, observability) transparently, managed by a central control plane.
