Low-Level Design (LLD), OOAD & Design Patterns

The Story: Designing a Single Building

• High-Level Design (HLD) is city planning — where roads go, where buildings stand.
• Low-Level Design (LLD) is architectural blueprints — how many rooms, where the wiring runs, how the elevator works.

LLD is about class design, object relationships, APIs, and algorithms for a specific module. You’re asked to design the internals of one component in enough detail that a developer can implement it without further clarification.

---

What LLD Covers

Concern	Examples
Class structure	What classes exist? What are their fields and methods?
Object relationships	Inheritance, composition, aggregation
Design patterns	How do components interact?
APIs	Method signatures, request/response contracts
Algorithms	How does the core logic work?
Database schema	Table structure for this module
Sequence flows	Request lifecycle step by step

LLD interview prompt examples:

• “Design a parking lot system”
• “Design an elevator system”
• “Design a library management system”
• “Design a chess game”
• “Design a vending machine”

---

Object-Oriented Analysis and Design (OOAD)

OOAD is the process of translating real-world requirements into classes and relationships.

Step 1: Identify Entities (Nouns)

Read the requirements and extract nouns → potential classes.

Requirements: “Design a library system where members can borrow books. Books have authors. Members can reserve books that are currently borrowed. Librarians manage the catalog.”

Nouns extracted: Library, Member, Book, Author, Reservation, Librarian, Catalog, BorrowRecord

Step 2: Identify Behaviors (Verbs)

Verbs become methods on the most natural owner class.

Verb	Owner class	Method
borrow a book	Member	member.borrow(book)
return a book	Member	member.return(book)
reserve a book	Member	member.reserve(book)
add book to catalog	Librarian	librarian.addBook(book)
search catalog	Library	library.search(query)

Step 3: Define Relationships

Relationship types:
IS-A      → Inheritance  (Librarian IS-A Member)
HAS-A     → Composition  (Library HAS-A Catalog)
USES-A    → Association  (Member USES-A Book via borrowing)

Step 4: Design Classes

from enum import Enum
from datetime import datetime, timedelta
from typing import Optional, List

class BookStatus(Enum):
    AVAILABLE = "available"
    BORROWED = "borrowed"
    RESERVED = "reserved"
    LOST = "lost"

class Book:
    def __init__(self, isbn: str, title: str, author: 'Author'):
        self.isbn = isbn
        self.title = title
        self.author = author
        self.status = BookStatus.AVAILABLE
        self.borrow_records: List['BorrowRecord'] = []

    def is_available(self) -> bool:
        return self.status == BookStatus.AVAILABLE

class Author:
    def __init__(self, name: str):
        self.name = name
        self.books: List[Book] = []

class Member:
    MAX_BORROW_LIMIT = 5
    BORROW_DURATION_DAYS = 14

    def __init__(self, member_id: str, name: str, email: str):
        self.member_id = member_id
        self.name = name
        self.email = email
        self.active_borrows: List['BorrowRecord'] = []
        self.reservations: List['Reservation'] = []

    def borrow(self, book: Book) -> 'BorrowRecord':
        if len(self.active_borrows) >= self.MAX_BORROW_LIMIT:
            raise Exception("Borrow limit reached")
        if not book.is_available():
            raise Exception("Book not available")

        record = BorrowRecord(
            member=self,
            book=book,
            due_date=datetime.now() + timedelta(days=self.BORROW_DURATION_DAYS)
        )
        book.status = BookStatus.BORROWED
        self.active_borrows.append(record)
        return record

    def return_book(self, book: Book) -> None:
        record = next((r for r in self.active_borrows if r.book == book), None)
        if not record:
            raise Exception("No active borrow for this book")
        record.return_date = datetime.now()
        self.active_borrows.remove(record)
        book.status = BookStatus.AVAILABLE
        # Notify first reservation holder if any
        self._fulfill_reservation(book)

    def _fulfill_reservation(self, book: Book) -> None:
        if book reservations exist:
            first_reservation = get_earliest_reservation(book)
            notify(first_reservation.member)
            book.status = BookStatus.RESERVED

class BorrowRecord:
    def __init__(self, member: Member, book: Book, due_date: datetime):
        self.member = member
        self.book = book
        self.borrow_date = datetime.now()
        self.due_date = due_date
        self.return_date: Optional[datetime] = None

    def is_overdue(self) -> bool:
        return self.return_date is None and datetime.now() > self.due_date

    def fine_amount(self) -> float:
        if not self.is_overdue():
            return 0.0
        overdue_days = (datetime.now() - self.due_date).days
        return overdue_days * 5.0  # ₹5 per day

class Reservation:
    def __init__(self, member: Member, book: Book):
        self.member = member
        self.book = book
        self.reserved_at = datetime.now()
        self.expires_at = datetime.now() + timedelta(days=3)

class Librarian(Member):  # IS-A Member with extra powers
    def add_book(self, catalog: 'Catalog', book: Book) -> None:
        catalog.add(book)

    def remove_book(self, catalog: 'Catalog', book: Book) -> None:
        if book.status == BookStatus.BORROWED:
            raise Exception("Cannot remove borrowed book")
        catalog.remove(book)

class Catalog:
    def __init__(self):
        self._books_by_isbn: dict[str, Book] = {}
        self._books_by_title: dict[str, List[Book]] = {}

    def add(self, book: Book) -> None:
        self._books_by_isbn[book.isbn] = book

    def search_by_title(self, title: str) -> List[Book]:
        return [b for b in self._books_by_isbn.values()
                if title.lower() in b.title.lower()]

    def search_by_author(self, author_name: str) -> List[Book]:
        return [b for b in self._books_by_isbn.values()
                if author_name.lower() in b.author.name.lower()]

    def get_by_isbn(self, isbn: str) -> Optional[Book]:
        return self._books_by_isbn.get(isbn)

---

Common LLD Problems

Pattern: State Machine (Vending Machine / Order System)

Many LLD problems are state machines. Identify states and transitions first.

from enum import Enum

class VendingState(Enum):
    IDLE = "idle"
    HAS_MONEY = "has_money"
    DISPENSING = "dispensing"
    OUT_OF_STOCK = "out_of_stock"

class VendingMachine:
    def __init__(self):
        self.state = VendingState.IDLE
        self.balance = 0.0
        self.inventory: dict[str, int] = {}  # product_id → count
        self.prices: dict[str, float] = {}   # product_id → price

    def insert_money(self, amount: float) -> None:
        if self.state not in (VendingState.IDLE, VendingState.HAS_MONEY):
            raise Exception("Cannot insert money in current state")
        self.balance += amount
        self.state = VendingState.HAS_MONEY

    def select_product(self, product_id: str) -> None:
        if self.state != VendingState.HAS_MONEY:
            raise Exception("Insert money first")
        if self.inventory.get(product_id, 0) == 0:
            self.state = VendingState.OUT_OF_STOCK
            raise Exception("Out of stock")
        price = self.prices[product_id]
        if self.balance < price:
            raise Exception(f"Insufficient balance. Need {price - self.balance} more")

        self.state = VendingState.DISPENSING
        self._dispense(product_id, price)

    def _dispense(self, product_id: str, price: float) -> None:
        self.inventory[product_id] -= 1
        self.balance -= price
        change = self.balance
        self.balance = 0
        self.state = VendingState.IDLE
        print(f"Dispensing {product_id}. Change: {change}")

Pattern: Observer (Notification System)

from abc import ABC, abstractmethod

class EventObserver(ABC):
    @abstractmethod
    def update(self, event_type: str, data: dict) -> None:
        pass

class NotificationService(EventObserver):
    def update(self, event_type: str, data: dict) -> None:
        if event_type == "book_returned":
            self._send_email(data['member_email'], "Your reserved book is available")

class AuditLogService(EventObserver):
    def update(self, event_type: str, data: dict) -> None:
        print(f"AUDIT: {event_type} at {datetime.now()} — {data}")

class EventPublisher:
    def __init__(self):
        self._observers: dict[str, list[EventObserver]] = {}

    def subscribe(self, event_type: str, observer: EventObserver) -> None:
        self._observers.setdefault(event_type, []).append(observer)

    def publish(self, event_type: str, data: dict) -> None:
        for observer in self._observers.get(event_type, []):
            observer.update(event_type, data)

---

UML Diagrams (The Language of LLD)

Class Diagram

Shows classes, their attributes, methods, and relationships.

┌─────────────────────────┐
│ <<class>>               │
│ Member                  │
├─────────────────────────┤
│ - member_id: str        │  ← attributes (- private, + public, # protected)
│ - name: str             │
│ - email: str            │
│ - active_borrows: List  │
├─────────────────────────┤
│ + borrow(book): Record  │  ← methods
│ + return_book(book)     │
│ + reserve(book)         │
└─────────────────────────┘
        ↑
        │ (inheritance / IS-A)
┌───────────────────┐
│ Librarian         │
├───────────────────┤
│ + add_book()      │
│ + remove_book()   │
└───────────────────┘

Relationships in UML:
──────────▷   Inheritance (IS-A)
- - - - - ▷   Implements interface
──────────◆   Composition (strong HAS-A, child can't exist without parent)
──────────◇   Aggregation (weak HAS-A, child can exist independently)
──────────→   Association (USES-A)

Sequence Diagram

Shows the order of interactions between objects for a specific use case.

User     :   Library  :  Catalog  :  Book  :  BorrowRecord
  |             |           |         |            |
  |──search()──→|           |         |            |
  |             |--search()→|         |            |
  |             |←─results──|         |            |
  |←──results───|           |         |            |
  |───borrow()-→|           |         |            |
  |             |────is_available?───→|            |
  |             |←───────true─────────|            |
  |             |─────set BORROWED───→|            |
  |             |───────────new Record────────────→|
  |             |←───────────record────────────────|
  |←──record────|           |         |            |

Activity Diagram

Flowchart showing the flow of logic (if/else, loops).

[Start]
   ↓
[Member selects book]
   ↓
<Is book available?> ── No ──→ [Reserve book] → [Notify when available] → [End]
   │ Yes
   ↓
<Member at borrow limit?> ── Yes ──→ [Reject with message] → [End]
   │ No
   ↓
[Create BorrowRecord]
   ↓
[Mark book as BORROWED]
   ↓
[Send confirmation email]
   ↓
[End]

---

LLD Interview Checklist

Step-by-step approach (15–20 minutes)

1. Clarify requirements (2 min): “What are the core use cases? Any specific constraints?”

2. Identify entities (2 min): Nouns from requirements → class names.

3. Sketch class diagram (5 min): Classes, key attributes, key methods, relationships.

4. Define key APIs (3 min): Method signatures for core operations.

5. Walk through a use case (3 min): Sequence diagram or pseudocode for the most complex flow.

6. Add design patterns (2 min): Observer, Strategy, Factory, Singleton — where appropriate.

7. Discuss extensibility (2 min): “If we needed to add X, the design supports it because…”

Questions to ask yourself

• What are the states in this system? (State machine)
• What changes frequently vs what is stable? (Strategy pattern)
• Who needs to be notified of events? (Observer pattern)
• Is there a family of algorithms? (Strategy/Template Method)
• Do I need to hide complex creation logic? (Factory/Builder)

---

Flashcards

Q: What is the difference between HLD and LLD?

HLD = system architecture (which components, how they connect). LLD = class design, method signatures, algorithms within a single component.

Q: What is the difference between composition and aggregation?

Composition = strong ownership, child can’t exist without parent (Library owns Catalog). Aggregation = weak ownership, child can exist independently (Library has Members, but Member can exist without Library).

Q: What does a sequence diagram show?

The order of interactions between objects over time for a specific use case.

Q: What is the Observer pattern?

An object (publisher) maintains a list of dependents (observers) and notifies them of events automatically. Used for event-driven decoupling.

Q: How do you approach an LLD interview problem?

Clarify requirements → identify entities (nouns) → identify behaviors (verbs) → design classes with relationships → define APIs → walk through a use case → discuss patterns and extensibility.
