Authentication, Authorization, JWT, OAuth2 & Security

The Story: The Gated City

Authentication = Proving who you are at the city gate. The guard checks your passport (identity). “Are you who you say you are?”

Authorization = What you’re allowed to do inside the city. Your visa says “tourist” — you can visit museums but not access government buildings. “Are you allowed to do this?”

These are two different questions. You must answer both, in order.

---

Authentication vs Authorization

	Authentication (AuthN)	Authorization (AuthZ)
Question	Who are you?	What can you do?
Mechanism	Password, biometric, OTP	Roles, permissions, policies
Output	Identity (user_id, claims)	Allow / Deny
Happens	First	Second (after AuthN)
Standards	OAuth2, OIDC, SAML	RBAC, ABAC, ACLs

A common confusion: OAuth2 is an authorization framework — it grants access tokens. OpenID Connect (OIDC) is the authentication layer built on top of OAuth2.

---

Sessions vs Tokens

Session-Based Authentication (Stateful)

1. User logs in with username + password
2. Server verifies credentials
3. Server creates a session: { session_id: "xyz123", user_id: 42, expires: T+24h }
4. Server stores session in DB or Redis
5. Server sends Set-Cookie: session_id=xyz123 to browser
6. Browser sends cookie with every request
7. Server looks up session_id in Redis → gets user_id → request proceeds

Problems:

• Server must maintain session state (not stateless)
• Horizontal scaling needs shared session store (Redis)
• Session store becomes bottleneck / SPOF

Token-Based Authentication (Stateless) — JWT

JWT (JSON Web Token): A signed token containing claims. Server verifies signature — no DB lookup needed.

JWT Structure:

header.payload.signature

Header (base64url encoded):
{
	"alg": "HS256",
	"typ": "JWT"
}

Payload (base64url encoded):
{
	"sub": "42",                 ← user_id
	"email": "[EMAIL_ADDRESS]",
	"roles": ["user", "admin"],
	"iat": 1706745600,           ← issued at
	"exp": 1706832000            ← expires at
}

Signature:
HMACSHA256(base64(header) + "." + base64(payload), secret_key)

Verification:

import jwt

def verify_token(token):
    try:
        payload = jwt.decode(
            token,
            SECRET_KEY,
            algorithms=["HS256"]
        )
        return payload  # contains user_id, roles, etc.
    except jwt.ExpiredSignatureError:
        raise UnauthorizedException("Token expired")
    except jwt.InvalidTokenError:
        raise UnauthorizedException("Invalid token")

Why JWT is stateless: The server only needs the secret key to verify any token. No DB lookup. No shared state. Horizontally scales perfectly.

JWT Trade-offs

Advantage	Disadvantage
Stateless — no DB lookup	Can’t invalidate before expiry
Scales horizontally	Token grows with claims
Self-contained claims	Must rotate secret key carefully
Works across domains/services	Payload is only base64 encoded — don’t put secrets in it

The JWT Revocation Problem

Problem: User logs out. JWT is valid for another 23 hours. If the token is stolen, attacker has 23 hours.

Solutions:

1. Short-lived access tokens: Expire in 15 minutes. Use refresh tokens for new access tokens.

Access token : 15 minutes TTL → short window of vulnerability
Refresh token: 30 days TTL    → stored securely, used to get new access tokens

If access token stolen  : attacker has 15 minutes
If refresh token stolen : user/system can revoke it (it's in DB)

2. Token blacklist (Redis): On logout, add JWT ID (jti) to Redis blacklist with TTL = token’s remaining lifetime.

def logout(token):
    payload = jwt.decode(token, SECRET_KEY, algorithms=["HS256"])
    remaining_ttl = payload['exp'] - time.time()
    redis.setex(f"blacklist:{payload['jti']}", int(remaining_ttl), 1)

def verify_token(token):
    payload = jwt.decode(...)
    if redis.exists(f"blacklist:{payload['jti']}"):
        raise UnauthorizedException("Token revoked")
    return payload

This re-introduces Redis dependency but is a targeted lookup (only blacklisted tokens).

---

OAuth 2.0: Delegated Authorization

Story: You want to print photos using a print shop. Instead of giving the print shop your Google Photos password, you authorize Google to give the print shop read-only access to your photos. The print shop never sees your password.

OAuth 2.0 solves: “How do I grant third-party app X access to my data on service Y, without sharing my password with X?”

The Four OAuth 2.0 Flows

Authorization Code Flow (for web apps with backend)

1. User clicks "Login with Google" on your app
2. Your app → redirects user to Google:
   https://accounts.google.com/oauth/authorize?
     client_id=YOUR_APP_ID
     &redirect_uri=https://yourapp.com/callback
     &scope=email profile
     &response_type=code
     &state=random_csrf_token

3. User logs in to Google, consents to permissions
4. Google → redirects user back to your app:
   https://yourapp.com/callback?code=AUTH_CODE&state=random_csrf_token

5. Your backend → exchanges code for tokens:
   POST https://oauth2.googleapis.com/token
   { code: AUTH_CODE, client_secret: YOUR_SECRET, ... }

6. Google → returns:
   { access_token: "...", refresh_token: "...", id_token: "..." }

7. Your app uses access_token to call Google APIs on user's behalf

Why code exchange? Security: The authorization code travels through the browser (URL redirect) — potentially visible. The code is exchanged for tokens in a backend-to-backend call (not browser), so tokens never touch the browser URL.

PKCE (Proof Key for Code Exchange) — for mobile/SPA

Mobile apps can’t securely store a client_secret. PKCE adds a code challenge/verifier so the code can only be exchanged by the original requester.

# 1. Generate code verifier and challenge
code_verifier = base64.urlsafe_b64encode(os.urandom(32)).rstrip(b'=').decode()
code_challenge = base64.urlsafe_b64encode(
    hashlib.sha256(code_verifier.encode()).digest()
).rstrip(b'=').decode()

# 2. Send code_challenge in authorization request
# 3. Send code_verifier in token exchange
# Server verifies: SHA256(code_verifier) == code_challenge

Client Credentials Flow (for machine-to-machine)

Service A   → POST /oauth/token { client_id, client_secret, grant_type=client_credentials }
Auth Server → { access_token: "..." }
Service A   → uses access_token to call Service B APIs

No user involved. Service authenticates as itself.

OpenID Connect (OIDC)

OAuth 2.0 + ID token = OpenID Connect. The id_token is a JWT containing the user’s identity.

{
  "iss": "https://accounts.google.com",
  "sub": "1098765432",              ← Google's user ID
  "email": "contact@ritiktiwari.com",
  "name": "Ritik Tiwari",
  "picture": "https://...",
  "aud": "your-client-id",
  "exp": 1706832000
}

OIDC is the standard for “Login with Google/GitHub/Apple/Microsoft” — you get the user’s identity in a standardised format.

---

Authorization Models

RBAC — Role-Based Access Control

Users are assigned roles. Roles have permissions.

Roles:
  admin  → [read, write, delete, manage_users]
  editor → [read, write]
  viewer → [read]

User Ritik → role: editor → can read and write, not delete or manage_users

DB schema:
users → user_roles → roles → role_permissions → permissions

Pros: Simple to understand, easy to audit
Cons: Role explosion (50 departments × 10 roles = 500 roles), hard to do fine-grained permissions

ABAC — Attribute-Based Access Control

Policies evaluate combinations of attributes (user, resource, environment).

def can_access(user, resource, action, context):
    # Policy: user can edit their own posts during business hours
    if action == "edit" and resource.type == "post":
        return (
            user.id == resource.author_id and
            context.hour in range(9, 18) and
            user.department == resource.department
        )
    return False

Pros: Fine-grained, flexible
Cons: Complex to manage, hard to audit (“why can’t I do X?”)

ACL — Access Control List

Each resource has a list of who can do what.

Document #42:
  user_1       → read, write
  user_2       → read
  group_admins → read, write, delete

Used by: Google Drive, AWS S3 bucket policies, Unix file permissions (rwx).

RBAC with Resource Ownership (Practical Hybrid)

def can_edit_post(user, post_id):
    post = get_post(post_id)

    # Check roles first
    if user.has_role("admin"):
        return True

    # Check resource ownership
    if post.author_id == user.id:
        return True

    # Check team-level permission
    if user.has_role("editor") and post.team_id in user.team_ids:
        return True

    return False

Most practical systems combine RBAC (coarse) with ownership checks (fine-grained).

---

Password Security

Hashing (Never store plaintext passwords)

import bcrypt

# Hash on registration
password = "user_secret_123"
hashed = bcrypt.hashpw(password.encode(), bcrypt.gensalt(rounds=12))
# Store hashed in DB — looks like: $2b$12$R.f5...

# Verify on login
def verify_password(plain_password, hashed_password):
    return bcrypt.checkpw(plain_password.encode(), hashed_password)

Why bcrypt (not SHA256)?

• bcrypt is intentionally slow (work factor). Making 12 = 2^12 iterations = ~250ms per hash.
• SHA256 is fast — attackers can compute billions/second. bcrypt limits to ~4/second per core.
• bcrypt includes salt automatically (prevents rainbow table attacks)

Alternatives: Argon2 (even better, winner of Password Hashing Competition), scrypt.

Common Auth Vulnerabilities

Attack	Description	Prevention
Brute force	Try all passwords	Rate limit login, account lockout
Credential stuffing	Use leaked username/password pairs	Check against HaveIBeenPwned, MFA
CSRF	Trick browser into making authenticated requests	CSRF token, SameSite cookie
XSS	Steal tokens from browser	HttpOnly cookies, CSP header
JWT secret compromise	Forge any token	Rotate secrets, short expiry
SQL injection	Extract hashed passwords from DB	Parameterised queries

---

Multi-Factor Authentication (MFA)

Authentication factors:

• Something you know: Password, PIN
• Something you have: Phone (OTP), hardware key (YubiKey)
• Something you are: Fingerprint, Face ID

MFA = two or more factors.

TOTP (Time-based One-Time Password)

1. User enables MFA → server generates secret key S
2. S shared to user's authenticator app (Google Auth, Authy)
3. Every 30 seconds: OTP = HOTP(S, floor(time/30))
   → Authenticator app and server compute same OTP using same S and time
4. Login: user enters password + 6-digit OTP from app
5. Server verifies OTP: compute TOTP(S) and compare

No network needed. Works offline. Standard RFC 6238.

---

Designing an Auth System for Scale

The auth service architecture

[Client] → [API Gateway] → validates JWT (no service call needed for stateless JWT)
                         → [Auth Service] (for login, signup, token refresh)
                         → [Resource Services] (user has been authenticated)

Auth Service owns:
  - Login/signup endpoints
  - Token issuance (access + refresh)
  - Token refresh
  - OAuth flows
  - MFA
  - Password reset

Token refresh flow

Client has:
  access_token  (valid 15 minutes)
  refresh_token (valid 30 days, stored in HttpOnly cookie)

T=0:    Client makes API request with access_token → success
T=14m:  Client makes API request → 401 Unauthorized (expired)
T=14m:  Client sends refresh_token to /auth/refresh
T=14m:  Auth Service:
          - validates refresh_token (check DB, not expired, not revoked)
          - issues new access_token (15 min)
          - optionally rotate refresh_token (sliding expiry)
          - returns new access_token
T=14m:  Client retries original request with new access_token → success

Where to store tokens in browsers

Storage	XSS risk	CSRF risk	Access from JS
localStorage	HIGH (JS can read it)	None	Yes
sessionStorage	HIGH (JS can read it)	None	Yes
HttpOnly Cookie	None (JS can’t read)	YES (auto-sent)	No
HttpOnly + SameSite=Strict Cookie	None	None	No

Best practice: Store refresh token in HttpOnly; SameSite=Strict cookie. Store access token in memory (JS variable) — lost on page refresh, which is acceptable since refresh token re-issues it.

---

Flashcards

Q: Design an authentication system

I’d use JWT for stateless auth with short-lived access tokens (15 min) and longer-lived refresh tokens (30 days). On login, validate credentials, hash comparison with bcrypt, issue both tokens. Access token in memory/header, refresh token in HttpOnly SameSite cookie. API gateway validates JWT signature without calling auth service — scales independently. For logout, add jti to Redis blacklist. For OAuth, use PKCE flow for mobile/SPA, Authorization Code for backend. MFA via TOTP for sensitive accounts.

Q: What is the difference between authentication and authorization?

Authentication = who you are (identity). Authorization = what you’re allowed to do (permissions). AuthN happens first.

Q: What makes JWT stateless?

The server verifies the signature using only its secret key — no DB or session store lookup needed.

Q: What is the JWT revocation problem?

JWTs can’t be invalidated before expiry. Solutions: short expiry (15 min) + refresh tokens, or jti blacklist in Redis.

Q: What is PKCE and why is it needed?

Proof Key for Code Exchange — adds a cryptographic challenge to OAuth’s Authorization Code flow for mobile/SPA apps that can’t safely store a client_secret.

Q: Why use bcrypt instead of SHA256 for password hashing?

bcrypt is intentionally slow (configurable work factor). Limits brute-force attempts. Includes automatic salt. SHA256 is fast — attackers can compute billions/second.

Q: What is RBAC?

Role-Based Access Control — users assigned roles, roles have permissions. Simple, auditable, but coarse-grained.

Q: Where should refresh tokens be stored in a browser?

HttpOnly, SameSite=Strict cookie. Not accessible to JavaScript (prevents XSS theft). SameSite prevents CSRF.
