Databases are the heart of any system. If your application is a city, your database is the vault — where truth lives. In this chapter, we’ll learn how data is stored, scaled, and accessed in real-world systems.

The Story: The City’s Record-Keeping System

The city is growing. We need to store information permanently. Not on sticky notes (cache), not shouted across the street (in-memory). We need a vault — structured, durable, queryable.

Two types of record keepers exist:

The Meticulous Archivist (SQL) The Flexible Warehouse Manager (NoSQL)
Every record follows a strict form. Accepts anything.
Relationships are explicit. No strict rules.
Extremely reliable. Blazing fast for the right use case.

SQL: The Meticulous Archivist

A relational database stores data in tables with a schema, and uses SQL to query.

Users table:
| id  | name  | email             | created_at          |
| --- | ----- | ----------------- | ------------------- |
| 1   | Ritik | ritik@example.com | 2026-03-19 10:30:00 |
| 2   | Dummy | dummy@example.com | 2026-03-19 09:00:00 |

Orders table:
| id  | user_id | amount | status    |
| --- | ------- | ------ | --------- |
| 101 | 1       | 599.00 | delivered |
| 102 | 1       | 299.00 | shipped   |
| 103 | 2       | 999.00 | pending   |

user_id in Orders is a foreign key — links to id in Users. This is a relationship.

ACID — The Four Guarantees

Property What it means City analogy
Atomicity All-or-nothing. Failure rolls everything back Transfer ₹1000; debit AND credit both happen, or neither does
Consistency DB always moves from valid state to valid state You can never have an order without a valid user
Isolation Concurrent transactions don’t see each other mid-flight Two people booking the last seat can’t both succeed
Durability Once committed, survives crashes After “Payment confirmed,” a power cut can’t erase it

Memory anchor: ACID = the bank’s promise to you.

When to use SQL

  • Financial data (transactions, ledgers)
  • User accounts and authentication
  • Any data with clear, stable relationships
  • When correctness > raw speed

Popular SQL databases: PostgreSQL, MySQL, SQLite

NoSQL: The Flexible Warehouse

Document Stores — The Filing Cabinet

Stores JSON-like documents. Each document can have different fields.

{
	"_id": "64a7f9e2b1c4d",
	"name": "Ritik Tiwari",
	"email": "ritik@example.com",
	"preferences": { "theme": "dark", "language": "en" },
	"addresses": [
		{ "type": "home", "city": "Auraiya" },
		{ "type": "work", "city": "Bangalore" }
	]
}

This would need 3 separate tables in SQL. Here it is only one document. Flexible schema allows for easy evolution.

Use when: User profiles, product catalogs, CMS

Tools: MongoDB, CouchDB

Key-Value Stores — The Locker Room

Pure: a key maps to a value. Fastest possible lookups.

"session:user_23"     → { "logged_in": true, "cart": [...] }
"rate:ip:1.2.3.4"     → 47
"cache:product:1001"  → { "name": "Laptop", "price": 45999 }

Use when: Session storage, caching, rate limiting, feature flags

Tools: Redis, DynamoDB, Memcached

Wide-Column Stores — The Spreadsheet That Scales to Billions

Each row can have completely different columns, runs across thousands of machines.

Row key: "user_23#2026-03-02"
Columns: { "page_view": "/home", "click": "buy_btn", "duration": 45 }

Row key: "user_23#2026-03-19"
Columns: { "page_view": "/product", "purchase": "SKU-001" }  // different columns!

Use when: Time-series data, IoT, analytics at massive scale

Tools: Apache Cassandra, HBase, Google Bigtable

Graph Databases — The Web of Connections

Nodes (entities) + edges (relationships). Fast at traversing connections.

(Dummy) --> [FOLLOWS]      --> (Ritik)
(Ritik) --> [LIKES]        --> (Post #42)
(Dummy) --> [COMMENTED_ON] --> (Post #42)

Use when: Social networks, recommendation engines, fraud detection

Tools: Neo4j, Amazon Neptune

SQL vs NoSQL Decision Framework

Strong relationships? Exact counts? Transactions?
       YES → SQL (PostgreSQL)
       NO
       ↓
High write throughput? Schema changes? Massive scale (PB+)?
       YES → NoSQL
       ↓
What data shape?
    JSON   →   MongoDB
    K-V    →   Redis
    Time   →   Cassandra
    Graph  →   Neo4j
Factor SQL wins NoSQL wins
Schema Known, stable Unknown, evolving
Transactions Critical Not critical
Query patterns Complex joins Simple key lookups
Scale Up to ~100M rows easily Billions of records
Consistency Strong required Eventual acceptable

Interview rule: Default to SQL. Upgrade to NoSQL with a specific justified reason.

Indexing: The Library Card Catalogue

Story: 10 million books in a library. Find “Game of Thrones” by checking every shelf (full table scan) — or use the card catalogue (index). The index is a sorted lookup structure pointing to where the data lives.

How an index works

-- Without index: scans ALL rows — O(n)
SELECT * FROM users WHERE email = 'ritik@example.com';

-- Create index
CREATE INDEX idx_users_email ON users(email);

-- Now uses B-tree binary search: O(log n) — microseconds

Index trade-offs

Operation Without index With index
SELECT (filter) Full scan — slow B-tree lookup — fast
INSERT/UPDATE/DELETE Fast Slower (index must update too)
Disk space Less More

Rule: Index columns in WHERE, JOIN ON, ORDER BY. Don’t index every column.

Composite indexes

-- Query: orders for user 1 that are 'delivered'
SELECT * FROM orders WHERE user_id = 1 AND status = 'delivered';

CREATE INDEX idx_orders_user_status ON orders(user_id, status);

Left-prefix rule: Index on (A, B, C) serves: A, A+B, A+B+C — but NOT B alone or C alone.

Database Replication: Multiple Record Rooms

Story: One master vault. If it burns, everything is lost. Smart cities keep certified duplicates.

Primary-Replica (Master-Slave) Replication

                               →   [Replica 1]   ← App reads
[App] writes → [Primary DB]    →   [Replica 2]   ← App reads
  (sync via WAL/binlog)        →   [Replica 3]   ← App reads
                               →   [Replica 4]   ← App reads

How it works

  1. All writes go to the primary
  2. Primary logs every change (WAL/binlog)
  3. Replicas apply the same changes
  4. Reads are distributed

Benefits

  • Read scalability
  • High availability
  • Geo distribution

The Replication Lag Problem

In a primary-replica setup, writes go to the primary, while reads are often served from replicas. The catch? Replicas are not updated instantly.

T=0:    User updates profile → write goes to Primary
T=0:    Primary confirms success
T=10ms: User reads → request hits Replica → sees OLD data
T=50ms: Replica catches up → now shows updated data

This delay is called replication lag — a short window where the system returns stale data.

Why This Happens

Replication is usually asynchronous:

  • Primary writes data
  • Changes are logged (WAL/binlog)
  • Replicas pull and apply changes slightly later

Trade-off: better performance vs temporary inconsistency

Solutions

  • Read-your-writes: After a user writes, route their reads to the primary for a short time
  • Synchronous replication: Primary waits for replicas before confirming (strong consistency, slower writes)
  • Monotonic reads: Ensure a user always reads from the same replica to avoid inconsistent results

Multi-Primary Replication

In this setup, multiple databases (primaries) can accept writes simultaneously — often used in multi-region systems.

User (India)  → writes → Primary (Asia)
User (US)     → writes → Primary (US)
User (EU)     → writes → Primary (EU)

This improves:

  • Low latency (users write to nearest region)
  • High availability (no single write bottleneck)

The Problem: Write Conflicts

If two users update the same data at the same time in different regions, conflicts occur.

T=0: User A (India) updates name → "Ritik"
T=0: User B (US) updates name → "Ricky"

Now both databases have different values ❌

Conflict Resolution Strategies:

  • Last Write Wins (LWW): The latest timestamp overwrites others, it is simple but can lose data
  • Application-level merge: Your application decides how to merge conflicts, it offers more control but adds complexity
  • CRDTs (Conflict-free Replicated Data Types): Special data structures that automatically merge changes. Used in collaborative systems (e.g., docs, chats)

Database Sharding: Splitting the Vault

As the system grows, a single vault (database) eventually becomes a bottleneck — not just in storage, but in how many requests it can handle. At some point, you can’t scale vertically anymore. We need to split the data across multiple databases — this is called sharding.

How this works

Horizontal partitioning across multiple DBs. Each shard stores only a subset of data, allowing horizontal scaling.

[All Users] → [Single DB] ❌ bottleneck

user_id % 4 → shard selection

Users 0,4,8... → Shard 0
Users 1,5,9... → Shard 1
Users 2,6,10... → Shard 2
Users 3,7,11... → Shard 3

Sharding Strategies

Range-based

user_id 1–1,000,000           → Shard 1
user_id 1,000,001–2,000,000   → Shard 2
Pros Cons
Efficient range queries (Easy queries) Uneven load distribution (hot shards)

Hash-based

shard = hash(user_id) % N
Pros Cons
Even data distribution (no hot shards) Range queries become hard (complex queries)
Re-sharding is painful

Consistent hashing Used in large-scale distributed systems.

Data and nodes are placed on a ring
Only a small portion of data moves when nodes change
Pros Cons
Minimal data movement Complex to implement

Sharding Challenges

Problem What it means Solution
Cross-shard queries JOINs across shards are slow/impossible Denormalize data
Hot shards One shard gets most traffic Better shard key / hashing
Resharding Adding shards requires moving data Plan ahead / consistent hash
Distributed transactions ACID across shards is extremely hard Avoid / use saga pattern

Important takeaway:

Sharding is powerful — but expensive in complexity. Use it only when absolutely necessary. Before sharding, try:

Indexing → Caching → Read Replicas → Vertical Scaling → Denormalization

Storage Types

Type Analogy Use Case
Block Raw disk Databases
File Shared drive Media
Object Infinite cloud storage Images/videos

Schema Design

Designing a good schema is one of the most important decisions in system design. A well-designed schema makes your system easier to scale, query, and maintain.

Practical Rules

  • Always have a primary key: Every row should be uniquely identifiable. Use uuid for distributed systems or auto-increment for simpler setups.

  • Use foreign keys (when possible): They enforce data integrity at the database level.

    Example: You should never have an order without a valid user.

  • Add timestamps everywhere: These help with debugging, analytics, and auditing.

  created_at, updated_at
  • Use soft deletes instead of hard deletes: This prevents accidental data loss and allows recovery.
  deleted_at (NULL if not deleted)

  • Index your foreign keys: Joins become significantly faster.

  • Use appropriate data types

    • VARCHAR(255) for emails
    • Avoid TEXT unless necessary
    • Use DECIMAL for money to avoid floating-point issues

Denormalization

In normalized databases, data is split across multiple tables to avoid duplication but sometimes we intentionally duplicate data to improve performance, then we need denormalization.

-- Normalized (This is clean and consistent — but requires joins)
SELECT t.content, u.name
FROM tweets t
JOIN users u ON t.user_id = u.id;

-- Denormalized (No JOIN needed → faster reads)
SELECT content, user_name
FROM tweets;

Trade-offs

Normalized Denormalized
No data duplication Data duplication exists
Strong consistency Risk of stale data
Slower reads (joins) Faster reads
Easier updates Harder to maintain

Quick Comparison

DB Type Best For
PostgreSQL Relational General purpose
MongoDB Document Flexible data
Redis Key-Value Cache/sessions
Cassandra Wide-column Massive scale

Interview Cheat Sheet

Step 1 — Ask

  • Schema type?
  • Relationships?
  • Read/write ratio?

Step 2 — Default

Start with PostgreSQL

Step 3 — Scale

  • Cache → Redis
  • Big data → Cassandra
  • Graph → Neo4j

Quick Recap

  • SQL = structure + consistency
  • NoSQL = flexibility + scale
  • Indexing = performance
  • Replication = availability
  • Sharding = scaling

Flashcards

Q: What does ACID stand for?

Atomicity, Consistency, Isolation, Durability

Q: What is replication?

Copying data for scaling and availability

Q: What is sharding?

Splitting data across DBs

Q: What is indexing?

Faster data lookup

Q: SQL vs NoSQL?

Structure vs flexibility
